TOA Electronics  |  SKU: TOA-MIC-PM660U

TOA PM-660U | Dynamic Cardioid Push to Talk Desktop Paging Microphone

$14250
Shipping calculated at checkout.

Condition: New



Description

TOA PM-660U Dynamic Cardioid Push to Talk Desktop Paging Microphone

TOAs PM-660U is an elegantly styled, compact desk ’ microphone for use in public address, paging and radio communication systems. Ideal applications include restaurants, offices, warehouses, transportation terminals, dispatch centers and entertainment facilities.

Key Features

  • Cardioid dynamic element
  • Elegant, space-saving integral stand design
  • Push-to-talk bar with locking lever
  • Extra switch contact for mute or relay control
  • Five year warranty

Technical Specifications

PERFORMANCE
Directivity
Unidirectional, cardioids pattern
Sensitivity (1 kHz)
-58 dB*
Frequency Response
100Hz-10kHz
Microphone Element
Dynamic (moving coil)
Impedance
600 ohm, balanced
CONTROLS
Push-To-Talk Bar
Microphone
Normally closed (mic element shorted)
Auxiliary Switch Contact
Normally open (dry contact)
Locking Lever
Locks push-to-talk bar in “on” position
PHYSICAL
Cable Length
Attached 8.2 with ’ stripped, tinned wire ends
Cable Type
2-C shielded (audio)
2-C (aux switch)
Finish
Microphone Head
Zinc plated steel mesh, gray baked paint
Stand / Base
Gray ABS resin
Dimensions W” x H”x D”)
3.9 x 8.5 x 5.9
Weight (Ibs)
0.97
